    360 Degree Red and Green Laser Level Module Laser Circle Beam Measuring Detector Scanner

    360 Degree Laser Level Module Red and Green Self-Leveling Laser Circle Beam Measuring Detector Scanner


    Product Description


    AIMLASER provides customized red and green 360 degree laser level modules, with different wavelengths, output power, line width, and dimensions. The laser projector emits a continuous laser circle beam using high-precision optical components, providing full 360-degree coverage.


    Our laser module has stable and accurate beam projection, making it suitable for demanding alignment, measuring, scanning, and self-leveling tasks in various industrial environments. They are used for floor leveling, wall tiling, ceiling installation, cabinetry alignment, and pipeline layout, and as the laser detector and scanner tool. Its 360° laser projection allows users to perform accurate measurements and alignment for construction, renovation, and industrial applications, improving efficiency and precision.


    The AM650R100G1 is a 360 degree red line laser generator, The maximum laser output power is 1.0 mW at 650nm.

    360 Degree Laser Level Module Red and Green Self-Leveling Laser Circle Beam Measuring Detector Scanner360 Degree Laser Level Module Red and Green Self-Leveling Laser Circle Beam Measuring Detector Scanner

    Specifications


    ITEMS

    SPECIFICATIONS

    Model Number

    360 Degree Red Laser Line Projector

    Wavelength

    650nm

    Output Power

    ≤1.0mW

    Output Power Ratio≤5:1

    Line Width

    ≤2.0mm@5m

    Line Accuracy

    ≤1.0mm@5m

    Fan Angle

    360°

    DOF1m

    Optics

    Optical Glass Lens

    Operating Current

    <100mA

    Operating Voltage

    3-5V or 12V or 24V DC

    CDRH Class

    Class IIIb

    Circuit control

    Auto Power Control (APC)

    Circuit Protection

    Static, Surge, and Reverse Polarity Protected

    Working Temperature

    -10℃ to 50℃

    Storage Temperature

    -40℃ to 80℃

    Dimensions

    Φ12x22mm (PCB Inside)

    Housing Material

    Black Anodized Aluminum

    Life Span

    8,000Hrs


    Features

    1. Compact size, long Lifetime, easy mounting.

    2. High reliability and stability, high brightness.

    3. High quality laser diode and optical glass lens

    4. Conform to ROHS, FDA, IEC, and SGS standards.

    5. Provide ONE year warranty and customized solutions.


    Applications


    The 650nm 1mW 360 Degree Red Line Laser Level Module is used in:


    ● Floor leveling and wall tiling
    Ceiling installation and cabinetry alignment
    Pipeline layout and calibration
    Construction and renovation projects
    Industrial alignment and positioning tasks
    Laser Line Maker and Laser Alignment Systems
    Laser Tape Measurer and Laser Distance Measurer
    3D Laser Scanner and Laser Survey Instrument
    Self-Leveling Laser Tools and Laser Measuring Tools


    Trade Terms


    1) Payment: T/T, PayPal, Western Union, etc.

    2) Shipment: FedEx, DHL, UPS etc.

    3) Delivery Time: 5 - 20 days.

    4) Shipment Terms: FOB Xi'an China


    Why Choose Us


    A. Over 20 years laser experience.

    B. Large-scaled facility 4,500sq.m2 and over 180 professional staffs.

    C. Use original LDs from Arima, Osram, Nicha and so on to guarantee reliability.

    D. Strictly following ISO9001:2008 quality system.

    E. Product conforms to FDA, IEC and GB standard.

    F. Strong design and production capabilities, partners of famous brands.
